Gearless elevator drives

  Inquiry Data Sheet  ◊ Compulsory to Fill In
  Person to Contact
  Phone Number
  Reference Number
  Technical Data
  Payload (kg)
  Car Weight (kg)
    Weight Compensation Factor (%)
  (Assume 50% If Not Specify)
    Hoistway Efficiency (%)
  (Assume 85% If Not Specify)
  Rope Suspension    1:1 2:1 Other (Please Specify)
  Rope Compensation (%)
  Travelling Speed (m/s)
  Lifting Height (m)
  Acceleration (m/s²)
  Weight of Travelling Cable (kg/m)
    Trips Per Hour
  (Assume 240 Trip Per Hour If Not Specify)
    Duty cycle (%)
  (Assume 40% If Not Specify)
    Traction Sheave Diameter (mm)
  Wire Rope Maker
  Wire Rope Type
  Wire Rope Breaking Force (KN)
  Weight of Wire Rope (kg/m)
  Rope Diameter (mm)
    Number of Rope (unit)
  Wrapping Angle, Single Wrap (°)
    Groove Shape    Semi-round Groove With Undercut (Standard)
   Special Groove (Please Specify If Any)
  Machine Mounting Position    Top Bottom Other (Please Specify)
  Deflection Pulleys (unit)
  Deflection Pulley Diameter (mm)
  Simple Bending:-
   unit = mm
   unit = mm
   unit = mm
   unit = mm
  Reverse Bending:-
   unit = mm
   unit = mm
   unit = mm
   unit = mm
    Overload Factor (%)
  (Assume 125% If Not Specify)
  Encoder (Heidenhain ECN 1313)    SSI Endat Other (Please Specify)
